Part Number	Type	Vs(V)	Test Voltage(V)	IRohm(MΩ)	Maximum Capacitance(pF)	Surge Current Capacity(A)	Surge Life Test(8/20μs,100A)
全部BK1XX00702BK1XX01002BK1XX01502BK1XX02002BK1XX02502BK1XX03002BK1XX03502BK1XX05002BK1XX07502BK1XX09002BK1XX10002BK1XX12002BK1XX13502BK1XX15002BK1XX18002BK1XX20002BK1XX22502BK1XX25002	全部-P	全部14020030040050060070010001500180020002400270030003600400045005000	全部50100250500	全部100	全部0.8	全部3000	全部250 times
BK1XX00702	-	140	50	100	0.8	3000	250 times
BK1XX01002	-	200	100	100	0.8	3000	250 times
BK1XX01502	-	300	100	100	0.8	3000	250 times
BK1XX02002	-	400	250	100	0.8	3000	250 times
BK1XX02502	-	500	250	100	0.8	3000	250 times
BK1XX03002	-	600	250	100	0.8	3000	250 times
BK1XX03502	-	700	250	100	0.8	3000	250 times
BK1XX05002	P	1000	500	100	0.8	3000	250 times
BK1XX07502	P	1500	500	100	0.8	3000	250 times
BK1XX09002	P	1800	500	100	0.8	3000	250 times
BK1XX10002	P	2000	500	100	0.8	3000	250 times
BK1XX12002	P	2400	500	100	0.8	3000	250 times
BK1XX13502	P	2700	500	100	0.8	3000	250 times
BK1XX15002	P	3000	500	100	0.8	3000	250 times
BK1XX18002	P	3600	500	100	0.8	3000	250 times
BK1XX20002	P	4000	500	100	0.8	3000	250 times
BK1XX22502	P	4500	500	100	0.8	3000	250 times
BK1XX25002	P	5000	500	100	0.8	3000	250 times
