| Part Number | Vrwm(V) | Vbr min.(V) | It(mA) | Vc(V) | Ipp(A) | Ir(μA) |
| 30KPA28A 30KPA28CA | 28.0 | 31.28 | 50 | 50.0 | 606.0 | 5000 |
| 30KPA30A 30KPA30CA | 30.0 | 33.51 | 50 | 55.2 | 548.9 | 5000 |
| 30KPA33A 30KPA33CA | 33.0 | 36.90 | 50 | 58.5 | 517.9 | 5000 |
| 30KPA36A 30KPA36CA | 36.0 | 40.20 | 50 | 61.8 | 490.3 | 5000 |
| 30KPA39A 30KPA39CA | 39.0 | 43.60 | 20 | 67.2 | 450.9 | 2000 |
| 30KPA42A 30KPA42CA | 42.0 | 46.90 | 10 | 72.0 | 420.8 | 1000 |
| 30KPA43A 30KPA43CA | 43.0 | 48.00 | 10 | 73.0 | 415.1 | 1000 |
| 30KPA45A 30KPA45CA | 45.0 | 50.30 | 5 | 77.4 | 391.5 | 250 |
| 30KPA48A 30KPA48CA | 48.0 | 53.60 | 5 | 81.6 | 371.3 | 150 |
| 30KPA51A 30KPA51CA | 51.0 | 57.00 | 5 | 86.4 | 350.7 | 50 |
| 30KPA54A 30KPA54CA | 54.0 | 60.30 | 5 | 91.4 | 331.5 | 20 |
| 30KPA58A 30KPA58CA | 58.0 | 64.80 | 5 | 92.4 | 327.9 | 20 |
| 30KPA60A 30KPA60CA | 60.0 | 67.00 | 5 | 102.0 | 297.1 | 15 |
| 30KPA64A 30KPA64CA | 64.0 | 71.50 | 5 | 104.0 | 291.3 | 10 |
| 30KPA66A 30KPA66CA | 66.0 | 73.70 | 5 | 107.0 | 283.2 | 2 |
| 30KPA70A 30KPA70CA | 70.0 | 78.20 | 5 | 109.0 | 278.0 | 2 |
| 30KPA71A 30KPA71CA | 71.0 | 79.30 | 5 | 111.5 | 271.7 | 2 |
| 30KPA72A 30KPA72CA | 72.0 | 80.40 | 5 | 114.0 | 265.8 | 2 |
| 30KPA75A 30KPA75CA | 75.0 | 83.80 | 5 | 119.4 | 253.8 | 2 |
| 30KPA78A 30KPA78CA | 78.0 | 87.10 | 5 | 129.0 | 234.9 | 2 |
| 30KPA84A 30KPA84CA | 84.0 | 93.80 | 5 | 139.2 | 217.7 | 2 |
| 30KPA90A 30KPA90CA | 90.0 | 100.50 | 5 | 146.4 | 207.0 | 2 |
| 30KPA96A 30KPA96CA | 96.0 | 107.20 | 5 | 156.0 | 194.2 | 2 |
| 30KPA102A 30KPA102CA | 102.0 | 113.90 | 5 | 165.6 | 183.0 | 2 |
| 30KPA108A 30KPA108CA | 108.0 | 120.60 | 5 | 175.2 | 172.9 | 2 |
| 30KPA120A 30KPA120CA | 120.0 | 134.00 | 5 | 194.4 | 155.9 | 2 |
| 30KPA132A 30KPA132CA | 132.0 | 147.40 | 5 | 213.0 | 142.3 | 2 |
| 30KPA144A 30KPA144CA | 144.0 | 160.80 | 5 | 223.2 | 135.8 | 2 |
| 30KPA150A 30KPA150CA | 150.0 | 167.60 | 5 | 233.4 | 129.8 | 2 |
| 30KPA156A 30KPA156CA | 156.0 | 174.30 | 5 | 245.0 | 123.7 | 2 |
| 30KPA160A 30KPA160CA | 160.0 | 178.70 | 5 | 252.6 | 120.0 | 2 |
| 30KPA168A 30KPA168CA | 168.0 | 187.70 | 5 | 272.4 | 111.2 | 2 |
| 30KPA170A 30KPA170CA | 170.0 | 189.90 | 5 | 275.0 | 110.2 | 2 |
| 30KPA180A 30KPA180CA | 180.0 | 201.10 | 5 | 290.4 | 104.3 | 2 |
| 30KPA198A 30KPA198CA | 198.0 | 221.20 | 5 | 319.8 | 94.7 | 2 |
| 30KPA216A 30KPA216CA | 216.0 | 241.30 | 5 | 348.6 | 86.9 | 2 |
| 30KPA240A 30KPA240CA | 240.0 | 268.10 | 5 | 387.0 | 78.3 | 2 |
| 30KPA258A 30KPA258CA | 258.0 | 288.20 | 5 | 416.4 | 72.8 | 2 |
| 30KPA260A 30KPA260CA | 260.0 | 290.40 | 5 | 416.0 | 72.8 | 2 |
| 30KPA270A 30KPA270CA | 270.0 | 301.60 | 5 | 436.2 | 69.5 | 2 |
| 30KPA280A 30KPA280CA | 280.0 | 312.80 | 5 | 464.0 | 65.3 | 2 |
| 30KPA288A 30KPA288CA | 288.0 | 321.70 | 5 | 469.9 | 64.5 | 2 |
